ENIG Black Solder Mask CEM-3 Rigid Multi Layer PCB Board

Product Categories

Abis Circuits Co., Ltd.

Contact Now

ENIG Black Solder Mask CEM-3 Rigid Multi Layer PCB Board

Certification : ISO14001, ISO9001, UL, cUL, TS16949

Place of Origin : China

MOQ : 1PCS

Price : Customized

Payment Terms : T/T, paypal, , Western Union etc.

Supply Ability : 60,000sqm per month

Delivery Time : 1-15 working days

Packaging Details : vacuum package

Material : CEM-3

Type : Customizable

Max. Size : 600mm x 1200mm

Minimum line : 0.075mm

Minimum space : 0.075mm

Solder mask color : Black

Legend color : White

Copper thickness : 2OZ

Drilling Hole : 0.15mm-6.35mm

Finish Hole : 0.10mm-6.30mm

Contact Now

CEM-3 Rigid Board Multi Layer PCB ENIG With Black Solder Mask In White Legend

1.Company introduction

Abis Circuits Co., Ltd is a professional PCB manufacturer which was established on Oct, 2006 and focus on

double side, Multilayer and HDI pcb mass production.

We have two factories together , the factory in Shenzhen is specialized in small and middle volume orders and the

factory in Huizhou is for big volume and HDI.

2.Factory

Operation plant space:

(I) 10000 Square meters

(II) 60000 Square meters

Employees:

(I) 300 Man Powers

(II) 900 Man Powers

Eng. Technical:

(I) 20 QA QC Engineers

(II) 60 QA,QC Engineers

Factory-examining:

ENIG Black Solder Mask CEM-3 Rigid Multi Layer PCB Board

3.Technological capability

No	Items	Capability
1	Layer Counts	1-20 layers
2	Material	FR4, High TG FR4, PTFE,Cu base, Rogers, Aluminium base, etc
3	Maximum Size	600mm x 1200mm
4	Board Outline Tolerance	±0.10mm
5	Board Thickness	0.20mm-8.00mm
6	Thickness Tolerance(t≥0.8mm)	±8%
7	Thickness Tolerance(t<0.8mm)	±10%
8	Insulation Layer Thickness	0.075mm-5.00mm
9	Minimum Line	0.075mm
10	Minimum Space	0.075mm
11	Out Layer Copper Thickness	18um-350um
12	Inner Layer Copper Thickness	17um-175um
13	Drilling Hole(Mechanical)	0.15mm-6.35mm
14	Finish Hole(Mechanical)	0.10mm-6.30mm
15	Diameter Tolerance(Mechanical)	0.05mm
16	Registration(Mechanical)	0.075mm
17	Aspect Ratio	16:01
18	Solder Mask Type	LPI
19	SMT Mini. Solder Mask Width	0.075mm
20	Mini. Solder Mask Clearance	0.05mm
21	Plug Hole Diameter	0.25mm*0.60mm
22	Impedance Control Tolerance	±10%
23	Surface Finish	HASL, Lead Free HASL, Immersion tin, Immersion gold, Gold plating, Immersion silver, OSP, etc.
24	Soldermask Color	Green, White, Black, Red, Yellow, Blue
25	Silkscreen Color	White, Black, Yellow, Blue

4.Lead time

Category	Quickest Lead time	Normal Lead Time	Mass Production
2 Layers	24hrs	3-4 working days	8-15 working days
4 Layers	48hrs	3-5 working days	10-15 working days
6 Layers	72hrs	3-6 working days	10-15 working days
8 Layers	96hrs	3-7 working days	14-18 working days
10 Layers	120hrs	3-8 working days	14-18 working days
12 Layers	120hrs	3-9 working days	20-26 working days
14 Layers	144hrs	3-10 working days	20-26 working days
16-20 Layers	Depends on the specific requirements
Above 20 Layers	Depends on the specific requirements

5.Manufacturing Equipment

ENIG Black Solder Mask CEM-3 Rigid Multi Layer PCB Board

6.Certificate

ENIG Black Solder Mask CEM-3 Rigid Multi Layer PCB Board

7.FAQ

Q1: What files do you use in PCB fabrication?
A1: Gerber, PCB. Auto CAD

Q2: How do you make sure the quality?
A2: Our Product is all 100% tested including Flying Probe Test (for sample), E-test (mass) or AOI.

Q3: Can we visit your company?
A3: Of course! Welcome to visit our company, Abis located in Shenzhen, Guangdong province, China.

Q4: What is your minimum order quantity (MOQ)?

A4: Our MOQ is 1 PCS, sample and mass production all can support.

Q5: Will you keep our information and files secret?
A5: Sure! It is our basic principle to keep business secrets to protect our customers' rights and behalf.

Q6. How to work with you?
A6: -Email and send us the PCB layout file, BOM list
- We will provide reply confirmation within 12 hours and reply to the offer within 3-5 days.
- Waiting for your company to confirm the price, order and payment method.
- We will start the production.
